Self Referential Structures in C: Pointers, Linked Lists, Trees

Here are the types of self-referential structures in C:

1. Self-Referential Structure with Single Link

A single link self-referential structure contains one pointer that points to the next instance of the same structure type. This is commonly used in singly linked lists.

‍

Example

#include <stdio.h>

struct Node {
    int data;
    struct Node *next;  // Single link to the next node
};

int main() {
    struct Node n1, n2, n3;

    n1.data = 10;
    n1.next = &n2; // Linking to next node

    n2.data = 20;
    n2.next = &n3; // Linking to next node

    n3.data = 30;
    n3.next = NULL; // End of the list

    printf("First Node: %d\n", n1.data);
    printf("Second Node: %d\n", n2.data);
    printf("Third Node: %d\n", n3.data);

    return 0;
}

Output

First Node: 10
Second Node: 20
Third Node: 30

Explanation

• The structure Node contains two fields: an integer data and a pointer next that links to the next node
• The first node (n1) points to the second node (n2), which in turn points to the third node (n3). The third node has no next node, indicating the end of the list.
• The data of each node is printed, showing the values stored in n1, n2, and n3.

2. Self-Referential Structure with Multiple Links

The self-referential structure with multiple links involves multiple pointers within the structure. This is useful when creating complex data structures like doubly linked lists or trees where nodes have more than one connection.

‍

Example

#include <stdio.h>

struct Node {
    int data;
    struct Node *next;  // Link to the next node
    struct Node *prev;  // Link to the previous node
};

int main() {
    struct Node n1, n2, n3;

    n1.data = 10;
    n1.next = &n2;
    n1.prev = NULL;

    n2.data = 20;
    n2.next = &n3;
    n2.prev = &n1;

    n3.data = 30;
    n3.next = NULL;
    n3.prev = &n2;

    printf("First Node: %d\n", n1.data);
    printf("Second Node: %d\n", n2.data);
    printf("Third Node: %d\n", n3.data);

    return 0;
}

Output

First Node: 10
Second Node: 20
Third Node: 30

Explanation

The Node structure has an integer data, a next pointer to the next node, and a prev pointer to the previous node. In the doubly linked list, n1 points to n2, n2 points to n3, and n3 points back to n2. The first node has no previous node, and the last node has no next node. Each node's data is printed.

Here is the example implementation of self-referential structure in C:

Creating a Linked List with Self-Referential Structure

C Code

#include <stdio.h>

struct Node {
    int data;
    struct Node *next;
};

void printList(struct Node *head) {
    struct Node *temp = head;
    while (temp != NULL) {
        printf("%d -> ", temp->data);
        temp = temp->next;
    }
    printf("NULL\n");
}

int main() {
    struct Node n1, n2, n3;

    n1.data = 10;
    n1.next = &n2;

    n2.data = 20;
    n2.next = &n3;

    n3.data = 30;
    n3.next = NULL;

    printList(&n1);  // Output: 10 -> 20 -> 30 -> NULL

    return 0;
}

Output

10 -> 20 -> 30 -> NULL

Explanation

• The structure Node holds an integer (data) and a pointer to the next node (next).
• The three nodes (n1, n2, n3) are linked together, forming a singly linked list where n1 points to n2, and n2 points to n3. n3 points to NULL, marking the end of the list.
• The printList function traverses the list, printing the data of each node until it reaches NULL, indicating the end.

Creating a Doubly Linked List with a Self-Referential Structure

C Code

#include <stdio.h>

struct Node {
    int data;
    struct Node *next;
    struct Node *prev;
};

void printList(struct Node *head) {
    struct Node *temp = head;
    while (temp != NULL) {
        printf("%d <-> ", temp->data);
        temp = temp->next;
    }
    printf("NULL\n");
}

int main() {
    struct Node n1, n2, n3;

    n1.data = 10;
    n1.next = &n2;
    n1.prev = NULL;

    n2.data = 20;
    n2.next = &n3;
    n2.prev = &n1;

    n3.data = 30;
    n3.next = NULL;
    n3.prev = &n2;

    printList(&n1);  // Output: 10 <-> 20 <-> 30 <-> NULL

    return 0;
}

Output

10 <-> 20 <-> 30 <-> NULL

Explanation

• The structure Node has a field of type integer named data, a pointer to the next node next, and a pointer to the previous node prev and as such, it is a doubly linked list.
• The three nodes (n1, n2, n3) are linked in both directions: n1 is giving the reference to n2, and n2 is giving the reference to n1 back.n2 is giving the reference to n3, and n3 is giving the reference to n2 back.n3 is pointing to NULL, thus, the end of the list is confirmed.

  • n1 is giving the reference to n2 and n2 is giving the reference back to n1.
  • n2 is giving the reference to n3 and n3 is giving the reference back to n2.
  • n3 is pointing to NULL, thus, the end of the list is confirmed.
  • The printList function, going through the nodes one after another, it is able to access and display the data of each node, starting from n1 and thus, going forward.

Creating a Tree with a Self-Referential Structure

C Code

#include <stdio.h>

struct Node {
    int data;
    struct Node *left;
    struct Node *right;
};

void printTree(struct Node *root) {
    if (root != NULL) {
        printf("%d ", root->data);
        printTree(root->left);
        printTree(root->right);
    }
}

int main() {
    struct Node n1, n2, n3, n4, n5;

    n1.data = 10;
    n1.left = &n2;
    n1.right = &n3;

    n2.data = 20;
    n2.left = &n4;
    n2.right = &n5;

    n3.data = 30;
    n3.left = NULL;
    n3.right = NULL;

    n4.data = 40;
    n4.left = NULL;
    n4.right = NULL;

    n5.data = 50;
    n5.left = NULL;
    n5.right = NULL;

    printTree(&n1);  // Output: 10 20 40 50 30

    return 0;
}

Output

10 20 40 50 30

Explanation

• The Node structure forms a binary tree with integer data and pointers to left (left) and right (right) child nodes. The nodes (n1, n2, n3, n4, n5) are arranged as:

  • n1 is the root, with n2 as the left child and n3 as the right child.
  • n2 has n4 (left) and n5 (right) as children.
  • n3, n4 and n5 have no children (NULL pointers.
• The printTree function performs a pre-order traversal, printing the node data from the root and recursively visiting each child.

Here are a few applications of self-referential structure in C, such as:

• Linked Lists: Nodes in linked lists use self-referential structures to store data and pointers to the next node, allowing flexible insertion and deletion.
• Stacks: A stack can be implemented using a linked list where each node points to the next, supporting dynamic memory allocation and LIFO behaviour.
• Queues: Similar to stacks, queues use linked lists to dynamically add elements from the rear and remove them from the front, following the FIFO principle.
• Binary Trees: Nodes in binary trees contain pointers to left and right children, allowing hierarchical data representation and traversal.
• Graphs: Self-referential structures allow efficient representation of graphs, where nodes point to adjacent nodes, forming an adjacency list.

These are the main advantages of using self-referential structures in C like:

• Dynamic Data Structures: With the help of self-referential structures, the users can establish data structures that are not only flexible but also can grow dynamically such as linked lists, trees, and graphs. These data structures can efficiently meet the changing data requirements during program execution.
• Efficient Memory Usage: Such structures allocate memory on a need basis only thus helping in the avoidance of memory wastage which is usually the case with static arrays.
• Flexibility: Self-referential structures give a possibility for a simple and fast insertion and deletion of elements that do not require the rearrangement of the whole structure as is the case with arrays.
• Implementation of Complex Structures: Self-referential structures are the most important aspects in the process of creating complex data structures like trees, linked lists, and graphs which are the main sources in many algorithms.
• Facilitates Advanced Operations: They allow for such complicated operations as tree traversals, graph searches, and dynamic memory management, which in turn gives the users flexibility for their various algorithmic needs.

Here are the disadvantages of using self-referential structures in C such as:

• Complexity: Implementing and managing these structures can be more complex than static data structures, often leading to bugs, especially in memory management.
• Memory Overhead: Each node requires additional memory for pointers, which can add significant overhead, particularly in structures with numerous small elements.
• Memory Fragmentation: Dynamic memory allocation and deallocation can cause memory fragmentation, especially in long-running applications that allocate and free memory frequently.
• Pointer Management: Improper handling of pointers can result in issues like memory leaks, dangling pointers, and segmentation faults, making pointer management critical.
• Performance Overhead: Operations like pointer dereferencing in self-referential structures tend to be slower than direct array indexing, introducing performance overhead.
• No Random Access: Unlike arrays, linked structures like linked lists don’t allow direct or random access to elements, leading to inefficiencies in accessing elements in specific scenarios.

To wrap it up, self referential structures in C language is a must for the creation of the dynamic data structures like linked lists, trees, and graphs, allowing the users to have the flexibility, efficient memory management, and even support for some advanced algorithms. Although these structures provide notable advantages such as being able to grow dynamically and facilitate easy element manipulation, they also encounter problems like complex nature, memory overhead, and possible pointer-related issues. Despite the disadvantages, these structures are still irreplaceable in many applications because of their capability to handle dynamic data and execute complex operations.

1. What is Self-Referential Data?

Self-referential data is data that includes references or pointers to the same type of data. For instance, in a linked list, every node has its data and a pointer to the next node (another example of the same data structure).

2. What is a Nested Structure?

A nested structure means one structure is inside another. This feature enables complex data models. The inner one can be a normal structure or a self-referential structure.

3. What is a Self-Referential Statement?

Self-referential statement means a situation where an entity is mentioning itself. Quite often, you may find this in C and C++ programming, e.g., when a structure or class is equipped with a pointer or reference to an instance of the same type.

4. What is a Self-Referential Relationship?

A self-referential relationship is a situation where an entity or a structure refers to the same entity or structure. In programming, especially with data structures, it is a case when an object, record, or structure has a reference or pointer to another instance of the same type. One of the easiest examples of this is a linked list, where each node contains the pointer of the next node of the same type.
